El-Bjorn TF 72EL EBC Electric Fan Heater - 3 Phase

The El-Bjorn TF 72EL is an industrial-grade electric fan heater that delivers powerful, efficient heating for large spaces. With its robust construction and high-powered 72kW heating capacity, this unit provides reliable temperature control for warehouses, factories, events, and more.

Unrivalled heating power

This fan heater's immense 72kW heating power is at its core, making it one of the most high-powered fan heaters available. The dual heat settings of 36kW and 72kW allow users to adapt the heating to match the size and demands of any space up to 1500m2. This incredible power ensures spaces of all types remain comfortably heated.

Optimised air distribution

The TF 72EL utilises specially designed air outlets and 360-degree airflow to distribute heat evenly across large areas. This prevents cold spots and guarantees a consistent, comfortable temperature throughout the space. The wide-span airflow makes the TF 72EL suitable for heating tall warehouses and expansive events.

Heavy-duty yet user-friendly

Despite its heavy-duty power, the TF 72EL retains an intuitive, user-friendly design. The built-in control card and display offer straightforward controls for overheating, fan speed, timers, and other settings. Users can easily dial in their preferred temperature for efficient, customisable heating. This combines industrial-grade power with accessible control.

With game-changing heating capacity and an optimised design, the El-Bjorn TF 72EL electric fan heater delivers unmatched temperature control for the largest spaces and harshest conditions. Its power, performance, and usability make it the go-to heating solution for factories, warehouses, and events with high heating demands.

Incoming 5-pol/400V 125A CEE 4125-6 1 pcs

Rated current 110 A

Voltage 3N~400V V

Total thermal power 72 kW

Output modes 36-72 kW

Air flow 7900/6454 m³/h

Temperature increase 40/47 °C

Noise level 69/63 dB(A)

Weight tot 180 kg

Weight top 72 kg

Weight bottom 96,5 kg

Weight distributor 11,5 kg

Dimensions exkl. distributor H x W x D (mm) 1400 x 740 x 1110 mm

Dimensions incl. distributor H x W x D 2250 x 740 x 1110 mm

Protection class IP44

Seasonal average efficiency (ηs) 36%

Dual Heat Settings: The 36kW and 72kW settings enable versatile heating options for spaces of all sizes up to an impressive 1500m2.

Corrosion-Resistant Construction: The galvanised steel build ensures durability and longevity even in harsh industrial conditions.

360-Degree Airflow: This allows for uniform heating distribution, eliminating cold spots for consistent comfort across large areas.

1500m2 Coverage Area: The massive heating capacity maintains adequate warmth even in extremely large warehouses, factories, and events.

Modular Design: Simplifies maintenance and cleaning, enhancing reliability.

Intuitive Controls: Adjusting the straightforward settings via the control card and display improves usability.
