El-Bjorn TF 36EL EBC Electric Fan Heater - 3 Phase

The El-Björn TF 36EL EBC electric fan heater is high-performance and designed to meet the needs of large, well-ventilated spaces. With dual settings of 18kW and 36kW, it allows you to cater to different environments. These settings make it ideal for commercial sites and event spaces. The powerful 3,850m³/h airflow and 360-degree distribution provide enough heat for spaces up to 600m².

Built to last

This electric fan heater is constructed with durability in mind, particularly the corrosion-resistant galvanised sheet steel body and a powder-coated finish. Despite its robust build, the TF 36EL remains lightweight and easy to transport, making it perfect for temporary setups. The compact design allows the electric heater to be placed in tight spot like stairwells and marquees, and it is easy to move between locations.

Advanced heating controls

Equipped with a smart control card and dual LED display, this heater makes it easy to manage settings and monitor the current and target temperatures. The controls are intuitive and easy to use, making fan speed and heat output easy to adjust. The lockable, password-protected display prevents any unauthorised access, and the automatic cool-down feature protects internal components.

Perfect for a range of applications

The El-Björn offers different modes, including “heating,” “drying,” and “event,” to fit your needs. Whether drying out damp areas, heating venues, or maintaining a climate during events, this unit can do it all. The built-in filters help maintain clean airflow and reduce maintenance frequency, adding to the heater's life span.

Incoming 5-pol/400V 63A CEE 463-6 1 pcs

Rated current 57 A

Voltage 3N~400V V

Total thermal power 36 kW

Output modes 18-36 kW

Air flow 4650/3850 m³/h

Temperature increase 29/34 °C

Noise level 68/63 dB(A)

Weight tot 127,5 kg

Weight top 41,5 kg

Weight bottom 77,5 kg

Weight distributor 8,5 kg

Dimensions exkl. distributor H x W x D (mm) 1200 x 740 x 935 mm

Dimensions incl. distributor H x W x D 2150 x 740 x 935 mm

Protection class IP44

Seasonal average efficiency (ηs) 36%

36kW / 18kW Double Heat Output: Provides flexible heating for different spaces.

Heats Up to 600m²: Ideal for large, well-ventilated spaces like warehouses and event areas.

360-degree Air Distribution: Evenly distributes heat across the entire area, eliminating cold spots.

Lightweight & Corrosion-Resistant Construction: Portable and durable design for long-lasting use.

Smart Control Card: Easy-to-use interface with a lockable, password-protected display for security.

Dual LED Thermostat Control: Allows precise temperature adjustments with a clear display of current and target temperatures.

Automatic Cool-Down Feature: Protects internal components and prolongs heater life.

Compact Footprint: Fits easily in confined spaces, enhancing versatility for various applications.
