Dustcontrol DC1800 H EX ATEX Zone 22 Rated Dust Extractor
Portable Zone 22 Rated Dust Extractor

Portable Dust Extraction for Hazard-Controlled Environments

The Dustcontrol DC1800 H EX is a compact 230V dust extractor designed for source extraction and general cleaning where Zone 22 rated equipment is required. Its low weight and small footprint support easy handling, while the steel container provides secure dust containment for maintenance and disposal tasks. The brushless motor enables spark-free operation for applications involving airborne industrial dust.

Filtration System

A polyester fine filter rated to Class M with 99.9 percent separation efficiency is combined with a HEPA H13 filter providing 0.85 m² surface area. Together, the filters achieve 99.995 percent overall machine separation efficiency in accordance with EN 60335-2-69 Appendix A-A. This supports extraction tasks involving particulates generated by cutting, grinding and general cleaning work.

Performance and Construction

The extractor delivers a maximum airflow of 200 m³/h and a peak negative pressure of 27 kPa for stable suction during tool-connected operation. The 20-litre steel container supports controlled dust storage, and the IP54-rated enclosure is suited to environments involving non-conductive dust. The DC1800 H EX operates at 70 dB(A) for continuous site use.

Supplied Equipment

The extractor is delivered with a 5 m Ø38 mm ATEX hose, ATEX floor nozzle, Ø38 mm suction pipe, polyester fine filter and HEPA H13 filter.

Buy at Climate Dry for dust extraction solutions suitable for Zone 22 rated work environments.

•  Dimensions: 840 x 400 x 400 mm
•  Weight: 16.5 kg
•  Inlet Diameter: 50 mm
•  Hose Diameter: 38 mm
•  Hose Length: 5 m
•  Container Capacity: 20 litres
•  Max Airflow (115V): 200 m³/h
•  Max Airflow (230V): 200 m³/h
•  Negative Pressure: 27 kPa
•  Power Input (115V): 1500 W
•  Power Input (230V): 1500 W
•  Fine Filter Area: 1.5 m²
•  Fine Filter Efficiency: 99.9 percent (Class M)
•  HEPA Filter Area: 0.85 m²
•  HEPA Classification: H13
•  Machine Separation Efficiency: 99.995 percent (Class H)
•  Max Sound Level: 70 dB(A)
•  Included Accessories: ATEX hose 5 m Ø38 mm ATEX floor nozzle suction pipe polyester filter HEPA H13 filter

• Zone 22 Compliance: Rated for dust extraction in designated hazard control areas
• Two Stage Filtration: Polyester fine filter and HEPA H13 stage for controlled particulate capture
• Spark Free Motor: Brushless design for operation with airborne dust
• Steel Container: 20 litre capacity for contained dust handling
• Supplied Components: Includes ATEX hose suction pipe floor nozzle fine filter and HEPA filter
• Stable Operation: Airflow and pressure suitable for tool extraction and general cleaning
