Air Conditioning Centre iPAC‑18-MOU 5kW Multi-Split Outdoor Air Conditioning Unit
18,000 BTU

iPAC-18-MOU 5kW Multi-Split Outdoor Air Conditioning Unit

Efficient Outdoor Unit for Multi-Zone Climate Control

The iPAC-18-MOU is a high-performance multi-split outdoor AC unit, designed to connect with up to two compatible indoor air conditioning units. With 5kW (18,000 BTU) cooling and heating capacity, it provides a flexible, energy-efficient solution for managing climate control across two rooms or zones. Suitable for small commercial spaces, offices, studios and larger residential and properties, the iPAC-18-MOU delivers robust year-round performance within a compact, discreet design.

Independent Dual-Zone Operation

Engineered for flexibility, this outdoor unit supports up two indoor units, enabling independent temperature control across two separate rooms or zones. Its inverter-driven compressor continuously adjusts output to match demand, maintaining stable, accurate comfort while reducing energy consumption. This makes it a cost-effective and practical alternative to installing multiple single-split systems.

Advanced Heat Pump Technology

As an energy-efficient heat pump system, the iPAC-18-MOU provides both cooling in summer and heating in winter. With energy ratings of A++ (cooling) and A+++ (heating), it delivers high output with reduced running costs, even in demanding outdoor conditions. The unit offers year-round performance, ensuring reliable climate control in homes, offices and light commercial spaces.

Durable & Quiet Outdoor Performance

Built for long-term external installation, the iPAC-18-MOU features a weather-resistant casing designed to withstand seasonal changes. Despite its strong capacity, the system runs with low noise levels, making it suitable for residential properties as well as commercial sites where quiet operation is essential. Featuring a compact, resilient and discreet design, it blends seamlessly into exterior spaces while delivering dependable indoor comfort.

Energy Efficiency Rating Cooling: A++
Energy Efficiency Rating Heating: A+++
Power Rating (Ph-V-Hz): 1/220-240V/50Hz
Capacity BTU/h (Cooling): kW 18000
Capacity BTU/h (Heating): kW 19000
Power Input (W) (Capacity): 1635 (690-2000)
Current Input (CH) (A): 7.3 / 6.6
EER/SEER (BTU/hr.W) SEER: 6.1
COP/SCOP (W/W) SCOP: 3.7
Outdoor Noise Level SPL dB(A) (Max): 54
Outdoor Airflow (m3/h): 2100
Max. Current Rating C/H (A) Fuse Rating (Type D): 9.0 / 7.95
Unit Dimensions (mm) Outdoor (WxDxH): 805x330x554
Net Weight Outdoor (kg): 35
Max. Input Consumption (W): 3050
Pipe Kit Included (Metre): N/A
Copper Pipe Size (Inch): 40
Max. Length for All Rooms (m): 25
Max. Length for One Indoor Unit (m): 15
Operating Temperature (°C): -15-50
Outdoor Gross Size (mm) (WxDxH): 915x370x615
Outdoor Gross Weight (kg): 38
